| Motion Detection 2.0 |
Deep learning-based motion detection 2.0 enabled by default for all analog channels. It can classify human and vehicle, greatly reducing false alarms caused by objects like leaves and lights. Quick search by object or event type is supported. |
| Perimeter Protection |
Human/Vehicle Analysis: Up to 4 channels |
| Facial Detection |
Facial Detection and Capture: Face picture detection, face picture search |
| Video and Audio |
IP Video Input: 4 channels (expandable to 12 channels) with up to 8 MP resolution; Enhanced IP mode supports up to 16 channels with 4 Mbps per channel. Supports H.265+/H.265/H.264+/H.264 IP cameras. Analog Video Input: 8 channels via BNC (1.0 Vp-p, 75 Ω), supporting coaxitron connection. |
| Video Outputs |
HDMI Output: 1 channel, up to 4K (3840 × 2160) at 30 Hz, 2K (2560 × 1440) at 60 Hz, 1920 × 1080 at 60 Hz, 1280 × 1024 at 60 Hz, 1280 × 720 at 60 Hz. Simultaneous HDMI/VGA output.
VGA Output: 1 channel, up to 1080p at 60 Hz.
|
| Audio I/O |
Audio Input: 1 channel, RCA (2.0 Vp-p, 1 KΩ).
Audio Output: 1 channel, RCA (Linear, 1 KΩ).
Two-Way Audio: 1 channel, RCA (2.0 Vp-p, 1 KΩ) using the first audio input.
|
| Recording |
Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264.
Encoding Resolution: 8 MP, 5 MP, 3K, 4 MP, 3 MP, 1080p, 720p, WD1, 4CIF, VGA, CIF.
Frame Rate: Main stream resolutions at varying frame rates. Sub-stream: WD1, 4CIF, CIF at 25/30 fps. Video Bitrate: 32 Kbps – 10 Mbps.
|
| Network |
Total Bandwidth: 128 Mbps.
Remote Connection: Up to 64 devices.
Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF.
Network Interface: 1× RJ45 10M/100M/1000M self-adaptive Ethernet interface.
|
| Storage & Ports |
SATA: 1 interface, supports up to 10 TB per disk.
Serial Interface: RS-485 (half-duplex).
USB Interface: 1× USB 2.0, 1× USB 3.0.
Alarm I/O: N/A
|
| General |
Power Supply: 12 VDC.
Consumption: ≤ 10 W.
Working Temperature: -10°C to +55°C (14°F to 131°F).
Working Humidity: 10% to 90%.
Dimensions: 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inches).
Weight: ≤ 2 kg (4.4 lbs).
|
Shipping: Available for immediate shipment
