| Facial Recognition |
| Face Picture Comparison |
Face image comparison and search (1-channel comparison alarm for HD analog camera) |
| Face Picture Library |
Up to 16 libraries |
| Motion Detection 2.0 |
| Human/Vehicle Analysis |
Enabled by default on all analog channels, can classify humans and vehicles, and significantly reduce false alarms from objects like leaves and lights |
| Quick Search |
Supported by object or event type |
| Perimeter Protection |
Human/vehicle analysis up to 2 channels |
| Video and Audio |
| IP Video Input |
2 channels (expandable to 6), up to 6 MP resolution |
| Analog Video Input |
4 channels, BNC (1.0 Vp‑p, 75 Ω), Coaxitron supported |
| HDTVI Input |
3K (2960×1665) @25/20fps, 3K (3328×1504) @20fps, 5MP @20fps, 4MP @25/30fps, 1080p @25/30fps, 720p @25/30fps |
| AHD Input |
5MP @20fps, 4MP/1080p/720p @25/30fps |
| HDCVI Input |
3K (2880×1620) @25fps, 5MP @20fps, 4MP/1080p/720p @25/30fps |
| CVBS Input |
Supports PAL/NTSC |
| CVBS Output |
1 channel, BNC (1.0 Vp‑p, 75 Ω), PAL: 704×576, NTSC: 704×480 |
| HDMI Output |
1 channel, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz; simultaneous HDMI/VGA |
| VGA Output |
1 channel, same resolutions as HDMI; simultaneous HDMI/VGA |
| Audio Input |
4-channel RCA (2.0 Vp‑p, 1 kΩ) + 4-channel via coaxial |
| Audio Output |
1-channel RCA (Linear, 1 kΩ) |
| Two-Way Audio |
1-channel RCA using first audio input |
| Synchronous Playback |
4 channels |
| Recording |
| Video Compression |
H.265 Pro+, H.265 Pro, H.265, H.264+, H.264 |
| Encoding Resolution |
Without 1080p Lite: 3K lite / 5MP lite / 4MP lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF
With 1080p Lite: same resolutions with "Lite" |
| Frame Rate (Main Stream) |
3K lite @12fps; 5MP/4MP lite @12-15fps; 1080p/720p/VGA/etc. @15-30fps depending on mode |
| Frame Rate (Sub Stream) |
WD1/4CIF @12fps; CIF @25fps (PAL) / 30fps (NTSC) |
| Video Bitrate |
32 Kbps to 6 Mbps |
| Dual-Stream |
Supports main or sub stream |
| Stream Type |
Video only or Video + Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Network |
| Remote Connections |
32 |
| Total Bandwidth |
72 Mbps |
| Protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network Interface |
1 × RJ-45 10/100 Mbps, self-adaptive |
| Wi-Fi |
Connectable via USB Wi-Fi dongle |
| Auxiliary Interfaces |
| SATA |
1 SATA interface, up to 10 TB per disk |
| Serial |
RS-485 (half-duplex) |
| USB |
Front: 1 × USB 2.0; Rear: 1 × USB 2.0 |
| Alarm In/Out |
Optional support; 4 in / 1 out |
| General |
| Power Supply |
12 VDC, 1.5 A |
| Power Consumption |
≤ 18 W (without HDD) |
| Working Temperature |
-10 °C to +55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimensions (W×D×H) |
319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inches) |
| Weight |
≤ 1.16 kg (2.6 lb) |
