| Motion Detection 2.0 |
Deep learning-based, enabled by default for all analog channels. Supports human/vehicle classification, reduces false alarms, and allows quick search by object/event type. |
| Perimeter Protection |
Human/Vehicle Analysis, up to 4 channels. |
| Facial Detection |
Face detection and capture, supports face image detection and search. |
| IP Video Input |
8 channels (up to 24). Enhanced IP mode: 16 channels (up to 32), each up to 4 Mbps. Supports up to 8 MP resolution. Compatible with H.265+/H.265/H.264+/H.264 IP cameras. |
| Analog Video Input |
16 channels, BNC interface (1.0 Vp-p, 75 Ω), coaxitron supported. |
| HDMI Output |
1 channel, resolutions: 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1080p/60Hz, 1280×1024/60Hz, 1280×720/60Hz. Simultaneous HDMI/VGA output. |
| VGA Output |
1 channel, resolutions: 1080p/60Hz, 1280×1024/60Hz, 1280×720/60Hz. Simultaneous HDMI/VGA output. |
| CVBS Input/Output |
Input: PAL/NTSC; Output: 1 channel BNC (1.0 Vp-p, 75 Ω), PAL: 704×576, NTSC: 704×480 |
| Synchronous Playback |
16 channels |
| HDTVI Input |
Up to 8 MP@15 fps, supports various resolutions including 3K, 5 MP, 4 MP, 3 MP, 1080p, 720p. |
| AHD Input |
Up to 5 MP@20 fps, supports 4 MP, 1080p, 720p. |
| HDCVI Input |
Up to 8 MP@15 fps, supports 5 MP, 4 MP, 1080p, 720p. |
| Audio Output |
1 channel, RCA (1 KΩ) |
| Audio Input |
1 channel (up to 16 optional), RCA (2.0 Vpp, 1 KΩ), 16 channels via coaxial |
| Two-Way Audio |
1 channel, RCA (2.0 Vp-p, 1 KΩ) |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
8 MP to CIF (various supported resolutions) |
| Frame Rate |
Main: Up to 8 MP@8 fps. Sub-stream: WD1/4CIF/CIF@25 fps(P)/30 fps(N) |
| Video Bitrate |
32 Kbps to 10 Mbps |
| Dual Stream |
Supported |
| Stream Type |
Video / Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Total Bandwidth |
128 Mbps |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Remote Connections |
128 |
| Network Interface |
1 × RJ45 10/100/1000 Mbps |
| Wi-Fi |
Supported via USB Wi-Fi dongle |
| SATA Interfaces |
2 SATA, up to 10 TB each |
| Serial Interface |
RS-485 (half-duplex) |
| USB Ports |
Front: 1 × USB 2.0; Rear: 1 × USB 3.0 |
| Alarm In/Out |
Not available (optional support) |
| Power Supply |
12 VDC, 5 A |
| Power Consumption |
≤ 19 W |
| Operating Temperature |
-10 °C to +55 °C (14 °F to 131 °F) |
| Humidity |
10% to 90% |
| Dimensions (W × D × H) |
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
| Weight |
≤ 2.1 kg (4.6 lb) |
