| Facial Recognition |
| Face Picture Library |
Up to 16 face picture libraries; HDD damage will not cause data loss as the library is backed up by HDD and flash. |
| Face Picture Comparison |
4-ch face picture comparison alarm (HD analog camera) |
| Motion Detection 2.0 |
| Human/Vehicle Analysis |
Deep learning-based motion detection 2.0 enabled by default for all analog channels; classifies human and vehicle; reduces false alarms from objects like leaves and lights; supports quick search by object or event type |
| Perimeter Protection |
| Human/Vehicle Analysis |
Up to 8-ch (advanced model) |
| Facial Detection |
Facial detection and capture; face picture detection, face picture search; 4-ch face picture capture |
| Video and Audio |
| IP Video Input |
8-ch (up to 40-ch), each up to 6 MP resolution |
| Analog Video Input |
32-ch; BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron connection |
| HDMI Output |
1-ch, 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output |
1-ch, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz; HDMI/VGA simultaneous output |
| CVBS Input |
PAL/NTSC |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω); Resolution: PAL: 704×576, NTSC: 704×480 |
| Synchronous Playback |
16-ch |
| HDTVI Input |
3K(2960×1665)@25/20fps, 3K(3328×1504)@20fps, 5 MP(2560×1944)@20fps, 4 MP(2560×1440)@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| AHD Input |
5 MP(2560×1944)@20fps, 4 MP(2560×1440)@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| HDCVI Input |
3K(2880×1620)@25fps, 5MP(2592×1944)@20fps, 4MP(2560×1440)@25/30fps, 1080P@25/30fps, 720P@25/30fps |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Audio Input |
1-ch (up to 16-ch optional), RCA (2.0 Vp-p, 1 KΩ), 32-ch via coaxial cable |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input) |
| Recording |
| Video Compression |
H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Encoding Resolution |
Without 1080p Lite mode: 3K lite / 5 MP lite / 4 MP lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF; With 1080p Lite mode: 3K lite / 5 MP lite / 4 MP lite / 1080p lite / 720p lite / VGA / WD1 / 4CIF / CIF |
| Frame Rate |
Main stream: see detailed rates by resolution (varies with 1080p Lite mode on/off);
Sub-stream: WD1/4CIF@12fps; CIF@25/30fps |
| Video Bitrate |
32 Kbps to 10 Mbps |
| Dual-stream |
Supports main stream or sub stream |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Decoding |
Up to 24-ch 1080P@30fps |
| Network |
| Total Bandwidth |
256 Mbps |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP |
| Remote Connection |
128 |
| Network Interface |
1 × RJ45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 12 TB per disk |
| Serial Interface |
RS-485 (half-duplex) |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 2 × USB 3.0 |
| Alarm In/Out |
N/A (optional support) |
| General |
| Power Supply |
12 VDC, 5 A |
| Consumption |
≤ 60 W |
| Working Temperature |
-10 °C to +55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
384 × 313 × 52 mm (15.1 × 12.3 × 2.0 inches) |
| Weight |
≤ 2.1 kg (4.6 lb) |
