| Motion Detection 2.0 |
Deep learning-based motion detection 2.0 enabled by default for all analog channels. It classifies human and vehicle targets to significantly reduce false alarms caused by objects like leaves and lights. |
| Quick Search |
Search by object or event type is supported. |
| Perimeter Protection |
Line Crossing Detection/Intrusion Detection. |
| Facial Detection |
Facial Detection and Capture: Face picture detection and search. |
| Video and Audio |
| IP Video Input |
2-ch (up to 18-ch) Enhanced IP mode: 8-ch (up to 24-ch), each up to 4 Mbps. Supports up to 6 MP resolution. Supports H.265+/H.265/H.264+/H.264 IP cameras. |
| Analog Video Input |
16-ch BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron connection. |
| Incoming Bandwidth |
96 Mbps |
| HDTVI Input |
3K(2960 × 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps. |
| AHD Input |
5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps. |
| HDCVI Input |
5 MP(2880 × 1620)@25 fps, 5 MP(2592 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps. |
| CVBS Input |
PAL/NTSC |
| HDMI Output |
1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Output |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Audio Input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Input (Coaxial) |
16-ch via coaxial cable |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Synchronous Playback |
16-ch |
| Recording |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
When 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF. When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF. |
| Frame Rate |
Main stream (when 1080p Lite mode is not enabled): 3K lite@12fps; 4 MP lite@15fps/1080pLite@20fps; 720p/WD1/4CIF/VGA/CIF@20fps. For 1080p Lite mode enabled: 3K lite/5 MP lite@12fps; 4 MP lite@15fps;1080p lite/720p lite@25fps. |
| Sub-stream |
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Video Bitrate |
32 Kbps to 6 Mbps |
| Dual-stream |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Network |
| Remote Connection |
128 |
| Total Bandwidth |
128 Mbps |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network Interface |
1, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| Auxiliary Interface |
| SATA |
1 SATA interface |
| Capacity |
Up to 10 TB capacity for each disk |
| USB Interface |
Front panel: 2 × USB 2.0 |
| Alarm In/Out |
N/A |
| General |
| Power Supply |
12 VDC, 2A |
| Consumption |
≤ 24W |
| Working Temperature |
-10 °C to +55 °C (+14 °F to +131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
285 × 210 × 48 mm (11.2 × 8.3 × 1.9 inch) |
| Weight |
≤ 1 kg (2.2 lb) |
