| Motion Detection 2.0 |
Deep learning-based motion detection 2.0, enabled by default for all analog channels. Can classify human and vehicle, reduces false alarms caused by objects like leaves and lights; quick search by object/event type is supported. |
| Perimeter Protection |
Human/Vehicle Analysis, up to 4 channels. |
| Facial Detection |
Facial Detection and Capture, supports face picture detection and search. |
| IP Video Input |
2 channels (up to 10 channels). Enhanced IP mode: 4 channels (up to 12 channels), each up to 4 Mbps. Supports up to 6 MP resolution, compatible with H.265+/H.265/H.264+/H.264 IP cameras. |
| Analog Video Input |
8 channels, BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron connection. |
| HDTVI Input |
3K (2960 x 1665) @ 20 fps, 5 MP (2560 × 1944) @ 20 fps, 4 MP (2560 × 1440) @ 30 fps, 4 MP (2560 × 1440) @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30 fps, 720p @ 25 fps. |
| AHD Input |
5 MP (2592 × 1944) @ 20 fps, 4 MP (2560 × 1440) @ 30 fps, 4 MP (2560 × 1440) @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30 fps, 720p @ 25 fps. |
| HDCVI Input |
5 MP (2592 × 1944) @ 20 fps, 4 MP (2560 × 1440) @ 30 fps, 4 MP (2560 × 1440) @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps, 720p @ 30 fps, 720p @ 25 fps. |
| CVBS Input |
Supports PAL/NTSC. |
| HDMI Output |
1 channel, 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz. |
| VGA Output |
1 channel, 1920 × 1080 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz. |
| Video Output Mode |
HDMI/VGA simultaneous output. |
| Audio Input |
1 channel, RCA (2.0 Vp-p, 1 KΩ), 8 channels via coaxial cable. |
| Audio Output |
1 channel, RCA (Linear, 1 KΩ). |
| Two-Way Audio |
1 channel, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input). |
| Synchronous Playback |
8 channels. |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264. |
| Encoding Resolution |
When 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF. |
| Frame Rate |
Main stream: When 1080p Lite mode is not enabled: For 3K stream access: 3K lite @ 12 fps; 4 MP lite/1080p @ 15 fps; 720p/WD1/4CIF/VGA/CIF @ 20 fps. |
| Video Bitrate |
32 Kbps to 6 Mbps. |
| Dual-stream |
Supported. |
| Stream Type |
Video, Video & Audio. |
| Audio Compression |
G.711u. |
| Audio Bitrate |
64 Kbps. |
| Network Total Bandwidth |
96 Mbps. |
| Remote Connection |
64. |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF. |
| Network Interface |
1 × RJ45 10/100 Mbps self-adaptive Ethernet interface. |
| Wi-Fi |
Connectable to Wi-Fi network by Wi-Fi dongle through USB interface. |
| SATA Interfaces |
1 SATA interface, up to 10 TB capacity for each disk. |
| Alarm In/Out |
N/A. |
| USB Ports |
Front: 2 × USB 2.0. |
| Power Supply |
12 VDC, 1.33 A. |
| Power Consumption |
≤ 12 W (without HDD). |
| Working Temperature |
-10 °C to +55 °C (+14 °F to +131 °F). |
| Working Humidity |
10% to 90%. |
| Dimensions (W × D × H) |
200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch). |
| Weight |
≤ 1 kg (without HDD, 2.2 lb.). |
