| Facial Recognition |
| Face Picture Library |
Up to 16 face picture libraries |
| Face Picture Comparison |
Face picture comparison, face picture search (2-ch face comparison alarm for HD analog camera) |
| Motion Detection 2.0 |
| Human/Vehicle Analysis |
Deep learning-based motion detection 2.0 enabled by default for all analog channels; classifies human and vehicle; reduces false alarms from objects like leaves and lights |
| Quick Search |
Supported by object or event type |
| Perimeter Protection |
| Human/Vehicle Analysis |
Up to 4 channels |
| Note |
Face picture comparison, motion detection 2.0, and perimeter protection cannot be enabled simultaneously; enabling one disables the other two |
| Video and Audio |
| IP Video Input |
4 channels (expandable to 12 channels), up to 6 MP resolution |
| Analog Video Input |
8 channels |
| BNC Interface |
1.0 Vp-p, 75 Ω, supports coaxitron connection |
| HDTVI Input |
3K (2960×1665)@25/20 fps, 3K (3328×1504)@20 fps, 5 MP (2560×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps |
| AHD Input |
5 MP (2560×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps |
| HDCVI Input |
3K (2880×1620)@25 fps, 5 MP (2592×1944)@20 fps, 4 MP (2560×1440)@25/30 fps, 1080P@25/30 fps, 720P@25/30 fps |
| CVBS Input |
PAL/NTSC |
| HDMI Output |
1 channel; 1920×1080@60Hz, 1280×1024@60Hz, 1280×720@60Hz; HDMI/VGA simultaneous output |
| VGA Output |
1 channel; 1920×1080@60Hz, 1280×1024@60Hz, 1280×720@60Hz; HDMI/VGA simultaneous output |
| CVBS Output |
1 channel, BNC (1.0 Vp-p, 75 Ω); PAL: 704×576, NTSC: 704×480 resolution |
| Audio Input |
8 channels RCA (2.0 Vp-p, 1 KΩ), 8 channels via coaxial cable; 4-ch RCA or 1-ch optional (up to 8-ch) via coaxial cable |
| Audio Output |
1 channel RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1 channel RCA (2.0 Vp-p, 1 KΩ) (uses first audio input) |
| Synchronous Playback |
8 channels |
| Recording |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding Resolution |
When 1080p Lite mode is OFF: 3K lite / 5 MP lite / 4 MP lite / 1080p / 720p / VGA / WD1 / 4CIF / CIF |
| |
When 1080p Lite mode is ON: 3K lite / 5 MP lite / 4 MP lite / 1080p lite / 720p lite / VGA / WD1 / 4CIF / CIF |
| Frame Rate (Main stream) |
- Without 1080p Lite mode: varies by resolution (12-30fps) |
| |
- With 1080p Lite mode: up to 30fps depending on resolution |
| Frame Rate (Sub-stream) |
WD1 / 4CIF @12fps; CIF @25/30fps |
| Video Bitrate |
32 Kbps to 6 Mbps |
| Dual-stream |
Supports main or sub-stream |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711u |
| Audio Bitrate |
64 Kbps |
| Network |
| Remote Connection |
Up to 64 |
| Total Bandwidth |
96 Mbps |
| Network Protocols |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Network Interface |
1 × RJ45 10/100 Mbps self-adaptive Ethernet interface |
| Wi-Fi |
Connectable via USB Wi-Fi dongle |
| Auxiliary Interface |
| Serial Interface |
RS-485 (half-duplex) |
| SATA |
1 SATA interface, supports up to 10 TB per disk |
| Alarm In/Out |
8 inputs / 4 outputs; optional 4 inputs / 1 output |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| General |
| Power Supply |
12 VDC, 1.5 A |
| Power Consumption |
≤ 18 W (without HDD) |
| Working Temperature |
-10 °C to +55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimensions (W × D × H) |
319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inches) |
| Weight |
≤ 1.78 kg (3.9 lb) (without HDD) |
