| Intelligent Analytics |
| AI by Device |
Facial recognition, perimeter protection, motion detection 2.0 |
| AI by Camera |
Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, VCA |
| Facial Recognition |
| Detection & Analytics |
Face picture comparison, human face capture, face picture search |
| Face Picture Library |
Up to 16 libraries, up to 20,000 face pictures total (each ≤ 4 MB, total ≤ 1 GB) |
| Analytics Performance |
1 channel, 8 MP |
| Face Picture Comparison |
4 channels |
| Motion Detection 2.0 |
| By Device |
All channels, 4 MP (up to 8 MP with enhanced SVC) video analysis for human and vehicle recognition to reduce false alarms |
| By Camera |
All channels |
| Perimeter Protection |
| By Device |
2 channels, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition |
| By Camera |
All channels |
| Video and Audio |
| IP Video Input |
32 channels |
| Incoming Bandwidth |
256 Mbps |
| Outgoing Bandwidth |
160 Mbps |
| HDMI Output |
1 channel, 4K (3840×2160) @ 30 Hz, 2K (2560×1440) @ 60 Hz, 1080p @ 60 Hz, and other resolutions |
| VGA Output |
1 channel, 1920×1080 / 1280×1024 / 1280×720 @ 60 Hz |
| Video Output Mode |
Independent HDMI/VGA |
| CVBS Output |
Not available |
| Audio Output |
1 channel, RCA (2.0 Vp-p, 1 kΩ, uses audio input) |
| Two-Way Audio |
1 channel, RCA (Linear, 1 kΩ) |
| Decoding |
| Decoding Format |
H.265/H.265+/H.264+/H.264 |
| Recording Resolutions |
12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Synchronous Playback |
16 channels |
| Decoding Capability |
AI ON: 1-ch@12 MP (30 fps), 2-ch@8 MP (30 fps), 4-ch@4 MP (30 fps), 8-ch@1080p (30 fps) |
| |
AI OFF: 2-ch@12 MP (30 fps), 3-ch@8 MP (30 fps), 6-ch@4 MP (30 fps), 12-ch@1080p (30 fps) |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw, G.711alaw, G.722, G.726, AAC |
| Network |
| Remote Connection |
128 |
| API |
ONVIF (profile S/G), SDK, ISAPI |
| Compatible Browsers |
IE11, Chrome V57+, Firefox V52+, Safari V12+, Edge V89+ |
| Network Protocols |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface |
1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface |
| SATA |
2 SATA interfaces |
| Capacity |
Up to 10 TB per HDD |
| USB Interface |
Front: 1 × USB 2.0; Rear: 1 × USB 2.0 |
| Alarm In/Out |
4 inputs / 1 output |
| General |
| GUI Language |
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz, Brazilian Portuguese, Indonesian |
| Power Supply |
12 VDC, 3.3 A |
| Consumption |
≤ 15 W (without HDD) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Dimension (W × D × H) |
385 mm × 315 mm × 52 mm (15.2" × 12.4" × 2.0") |
| Weight |
≤ 1 kg (without HDD, 2.2 lb.) |
| Certification |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| CE |
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
| Obtained Certification |
CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS |
