| Intelligent Analytics |
- AI by Device: Facial recognition, perimeter protection, motion detection 2.0
- AI by Camera: Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, VCA |
| Facial Recognition |
- Detection & Analytics: Face-picture comparison, human face capture, face-picture search
- Face Picture Library: Up to 16 libraries, ≤ 20,000 images total (each ≤ 4 MB, total ≤ 1 GB)
- Analytics Performance: 1 channel @ 8 MP - Face Picture Comparison: 4 channels |
| Motion Detection 2.0 |
- By Device: All channels, 4 MP (up to 8 MP with enhanced SVC), video analysis for human and vehicle recognition to reduce false alarms
- By Camera: All channels |
| Perimeter Protection |
- By Device: 2 channels, 4 MP (HD network cameras, H.264/H.265), video analysis for human and vehicle recognition to reduce false alarms
- By Camera: All channels |
| Video & Audio |
- IP Video Input: 32 channels - Incoming Bandwidth: 256 Mbps - Outgoing Bandwidth: 160 Mbps
- HDMI Output: 1 channel, 4K (3840×2160)@30Hz, 2K (2560×1440)@60Hz, 1080p@60Hz, and other resolutions
- VGA Output: 1 channel, 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz
- Video Output Mode: Independent HDMI/VGA outputs
- CVBS Output: Not available
- Audio Output: 1 channel RCA (2.0 Vp-p, 1 KΩ, uses audio input)
- Two-Way Audio: 1 channel RCA (Linear, 1 KΩ) |
| Decoding |
- Formats: H.265/H.265+/H.264+/H.264 - Recording Resolution: 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- Synchronous Playback: 16 channels
- Decoding Capacity:
• AI On: 1-ch@12 MP (30 fps), 2-ch@8 MP (30 fps), 4-ch@4 MP (30 fps), 8-ch@1080p (30 fps)
• AI Off: 2-ch@12 MP (30 fps), 3-ch@8 MP (30 fps), 6-ch@4 MP (30 fps), 12-ch@1080p (30 fps)
- Stream Type: Video, Video & Audio
- Audio Compression: G.711ulaw, G.711alaw, G.722, G.726, AAC |
| Network |
- Remote Connections: 128
- API: ONVIF (profile S/G), SDK, ISAPI - Compatible Browsers: IE11, Chrome 57+, Firefox 52+, Safari 12+, Edge 89+
- Protocols: TCP/IP, DHCP, IPv4/IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
- Network Interface: 1 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet |
| PoE |
- Interfaces: 16 × RJ-45 10/100 Mbps self-adaptive Ethernet
- Power Budget: ≤ 200 W - Standard: IEEE 802.3af/at |
| Auxiliary Interface |
- SATA: 2 ports (up to 10 TB capacity per HDD)
- USB: Front 1 × USB 2.0; Rear 1 × USB 2.0
- Alarm In/Out: 4 inputs / 1 output |
| General |
- GUI Languages: 40+ (including English, Russian, German, Arabic, etc.) - Power Supply: 100–240 VAC, 50/60 Hz
- Consumption: ≤ 15 W (without HDD and PoE off)
- Operating Temperature: -10 °C to 55 °C (14 °F to 131 °F) - Humidity: 10% to 90% RH
- Dimensions (W × D × H): 385 mm × 315 mm × 52 mm (15.2" × 12.4" × 2.0")
- Weight: ≤ 3 kg (without HDD, 6.6 lb) |
| Certification |
- FCC: Part 15 Subpart B, ANSI C63.4-2014
- CE: EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:2017
- Other Approvals: CE, FCC, IC, CB, KC, UL, RoHS, REACH, WEEE, RCM, UKCA, LOA, BIS |
