| Intelligent Analytics |
AI by Device: Facial recognition, perimeter protection, motion detection 2.0
AI by Camera: Facial recognition, perimeter protection, video structuralization, throwing objects from building, motion detection 2.0, ANPR, people counting, VCA
Engine: 1, engine mode is adjustable |
| Facial Recognition |
Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
Face Attributes: Wearing glasses, wearing a mask, facial expression, body temperature
Face Picture Library: Up to 16 libraries, with up to 50,000 pictures total (each ≤ 512 KB, total ≤ 1 GB)
Face Picture Comparison (Captured from Camera): 8-ch
Facial Detection and Analytics Performance: 4-ch human face capture (HD network camera, up to 2 MP, H.264/H.265) |
| Motion Detection 2.0 |
By Camera: All channels
By Device: All channels for Hikvision cameras |
| Perimeter Protection |
By Camera: All channels
By Device: 4-ch, 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm; Up to 12 rules in total |
| ANPR (Automatic Number Plate Recognition) |
By Camera: All channels
Vehicle Attributes: Plate number, license plate color, license plate type
Plate Attributes: Vehicle brand, vehicle color, vehicle type |
| Video and Audio |
IP Video Input: 32-ch
Incoming Bandwidth: 256 Mbps
Outgoing Bandwidth: 256 Mbps
HDMI 1 Output: 4K (3840×2160)/60Hz, 4K (3840×2160)/30Hz, 2K (2560×1440)/60Hz, 1920×1080/60Hz, HDMI1/VGA simultaneous output
HDMI 2 Output: 1920×1080/60Hz, HDMI2/VGA independent output
VGA Output: 1-ch, 1920×1080/60Hz, HDMI1/VGA simultaneous output
Video Output Mode: HDMI1/VGA simultaneous output, HDMI2/VGA independent output
CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), PAL: 704×576, NTSC: 704×480
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Decoding |
Decoding Format: H.265+/H.265/H.264+/H.264
Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIFNVR supports up to 4-ch 32 MP/24 MP IP video inputs
Synchronous Playback: 16-ch
Live View Window Division: 1/2/4/6/8/9/16/25/32/36
Aux Port Window Division: 1/2/4/6/8/9/16
Decoding Capability: Enable AI: 20-ch @1080p (30 fps), Disable AI: 32-ch @1080p (30 fps)
Dual-Stream Recording: Supported
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
| Network |
Network Interface: 2 × RJ-45 10/100/1000 Mbps self-adaptive Ethernet
Remote Connection: 128
Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF (Version 2.2), OTAP
API: ONVIF (profile S/G), SDK, ISAPI
Compatible Browser: IE11, Chrome V57+, Firefox V52+, Safari V12+, Edge V89+
Camera Access Protocol: ONVIF (Version 2.5), RTSP |
| Auxiliary Interface |
Serial Interface: 2 RS-485 (half-duplex), 1 RS-232
SATA: 4 SATA interfaces
Capacity: Up to 14 TB per disk
eSATA: 1 interface
Alarm In/Out: 16/9
USB Interface: Front: 2 × USB 2.0; Rear: 1 × USB 3.0
Ctrl 12V: Controllable 12 VDC, 1 A power output for external alarm device (controlled by alarm output 9)
DC 12V: 12 VDC, 1 A power output |
| General |
GUI Language: 40+ languages including English, Russian, Arabic, German, Japanese, Korean, Traditional Chinese, Hebrew, and more
Power Supply: 100 to 240 VAC, 50 to 60 Hz
Consumption: ≤ 30 W (without HDD)
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10% to 90%
Chassis: 19-inch rack-mounted 1.5U chassis
Dimension (W × D × H): 445 × 391 × 75 mm (17.5" × 15.4" × 3.0")
Weight: ≤ 3.6 kg (without HDD, 7.9 lb.) |
| Certification |
CE, CB, REACH, WEEE, UKCA, LOA
CE Standards: EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
