| Image Sensor |
1/2.4" Progressive Scan CMOS |
| Max. Resolution |
3200 × 1800 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 105°, V 55°, D 127°
4 mm: H 78°, V 38°, D 96° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.6 |
| DORI |
2.8 mm: Detect 76 m, Observe 30 m, Recognize 15 m, Identify 7 m
4 mm: Detect 115 m, Observe 45 m, Recognize 23 m, Identify 11 m |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
IR: up to 30 m, White Light: up to 20 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 20 fps (3200×1800, 2688×1520, 1920×1080, 1280×720)
60 Hz: 20 fps (3200×1800, 2688×1520, 1920×1080, 1280×720) |
| Sub-Stream |
50 Hz: 20 fps (1280×720, 640×480, 640×360)
60 Hz: 20 fps (1280×720, 640×480, 640×360) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Audio Type |
Mono sound |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711 ulaw/alaw), 16 Kbps (G.722.1/G.726), 32–160 Kbps (MP2L2), 16–64 Kbps (AAC-LC) |
| Security |
Password protection, complex password, watermark, HTTP authentication, WSSE, MAC authentication, audit logs |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF Profile S, T, G (-F model only), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Users |
Up to 32 (Administrator, Operator, User) |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 10, 11 (plugin required), Chrome 57+, Firefox 52+ |
| WDR |
120 dB |
| SNR |
≥ 52 dB |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Rotate, saturation, brightness, contrast, sharpness, gain, white balance; adjustable via client or browser |
| Privacy Mask |
4 programmable polygon masks |
| Ethernet Interface |
1 RJ45 10/100 M self-adaptive port |
| On-board Storage |
-F: microSD/microSDHC/microSDXC slot up to 256 GB |
| Built-in Microphone |
Yes |
| Reset Key |
-F: Yes |
| Basic Event |
Motion detection (support human & vehicle), video tampering alarm, exception |
| Event Linkage |
Upload to FTP/memory card (-F), send email, notify center, trigger recording (-F), trigger capture |
| Power |
12 VDC ± 25%, 0.41 A, max 5 W, Ø5.5 mm coaxial plug, reverse polarity protection; PoE IEEE 802.3af, Class 3, max 6.5 W |
| Material |
Metal & Plastic |
| Dimensions |
170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") |
| Package Dimensions |
216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6") |
| Weight |
Approx. 285 g (0.6 lb.) |
| Package Weight |
Approx. 481 g (1.1 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity ≤ 95% (non-condensing) |
| Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity ≤ 95% (non-condensing) |
| Languages |
English, Ukrainian |
| General Functions |
Heartbeat, anti-banding, mirror, password protection, password reset via email |
| Certifications |
EMC: CE-EMC (EN 55032:2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014),
RCM: AS/NZS CISPR 32:2015,
IC: ICES-003: Issue 7 |
| Safety |
UL: UL 62368-1,
CB: IEC 62368-1:2014+A11,
CE-LVD: EN 62368-1:2014/A11:2017,
BIS: IS 13252 (Part 1):2010/IEC 60950-1:2005 |
| Environment |
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protection |
IP67 (IEC 60529-2013) |
