| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Max. Resolution |
3840 × 2160 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens Type |
Fixed focal, 2.8 mm / 4 mm optional |
| FOV |
2.8 mm: H 105.1°, V 54.8°, D 128.2°
4 mm: H 90.0°, V 45.8°, D 109.4° |
| Lens Mount |
M16 |
| Aperture |
F1.0 |
| Depth of Field |
2.8 mm: 3.3 m–∞ / 4 mm: 3.8 m–∞ |
| DORI (2.8 mm) |
D: 89 m, O: 35 m, R: 17 m, I: 8 m |
| DORI (4 mm) |
D: 109 m, O: 43 m, R: 21 m, I: 10 m |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
Up to 40 m |
| IR Wavelength |
850 nm |
| Smart Supplement Light |
Yes |
| Main Stream |
50Hz: 25 fps (3840×2160, 3200×1800, etc.)
60Hz: 24–30 fps (depending on resolution) |
| Sub/Third Stream |
Up to 30 fps (res. dependent), third stream optional |
| Video Compression |
H.265/H.264/H.264+/H.265+, MJPEG (sub) |
| Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression |
-U: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC |
| Audio Bit Rate |
8 to 320 Kbps (depending on format) |
| Audio Sampling Rate |
-U: Up to 48 kHz |
| Environment Noise Filtering |
-U: Yes |
| Network Protocols |
TCP/IP, HTTP, HTTPS, FTP, RTSP, UPnP, SMTP, SNMP, etc. |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (S/G/T), ISAPI, SDK, ISUP |
| Security |
Password, IP filter, HTTPS, TLS 1.3, WSSE, digest auth., etc. |
| Network Storage |
NAS, ANR |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
IE 10/11, Chrome, Firefox, Edge (local service supported) |
| Image Settings |
Rotate, mirror, brightness, contrast, WDR (130 dB), etc. |
| SNR |
≥ 52 dB |
| Privacy Mask |
4 polygonal masks |
| On-Board Storage |
microSD up to 512 GB |
| Built-in Microphone |
-U: Yes |
| Reset Key |
Yes |
| Events |
Motion, tamper, exception, scene change |
| Perimeter Protection |
Line crossing, intrusion, human/vehicle filter |
| Face Capture |
Yes |
| Power |
12V DC ±25%, Max 7W; PoE (802.3af), Max 8.5W |
| Material |
Metal (body, bracket, cover) |
| Dimensions |
Ø74.4 × 179.2 mm (Ø2.9" × 7.1") |
| Package Dimensions |
234 × 120 × 117 mm |
| Weight |
Approx. 525 g (750 g with package) |
| Operating/Storage Temp |
-30 °C to 60 °C, ≤95% RH (non-condensing) |
| Languages |
Supports 33 languages |
| General Functions |
Heartbeat, pixel counter, anti-banding, etc. |
| EMC / Safety / Env. |
CE, UL, BIS, RoHS, WEEE, IP67 (dust/waterproof) |
