| Image Sensor |
1/2.4" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.008 Lux @ (F1.2, AGC ON), 0.014 Lux @ (F1.6, AGC ON) |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360° |
| Focus |
Fixed |
| Lens Type |
2.8/4/6 mm |
| Field of View |
2.8 mm: H: 99°, V: 61°, D: 128°
4 mm: H: 80°, V: 51°, D: 101°
6 mm: H: 60°, V: 38° |
| Aperture |
F1.6 |
| Lens Mount |
M12 |
| Aperture Type |
Fixed |
| IR Range |
Up to 30 m |
| Wavelength |
850 nm |
| Max. Resolution |
3072 × 2048 |
| Main Stream |
50Hz: 20 fps (3072×2048, 3072×1728, 2944×1656), 25 fps (2560×1440, 1920×1080, 1280×720)
60Hz: 20 fps (3072×2048, 3072×1728, 2944×1656), 30 fps (2560×1440, 1920×1080, 1280×720) |
| Sub Stream |
50Hz: 25fps; 60Hz: 30fps (640×480, 640×360, 320×240) |
| Third Stream |
50Hz: 25fps; 60Hz: 30fps (1280×720, 640×360, 352×288/240) |
| Compression |
H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264/H.265 Profile |
Main / High |
| H.264+/H.265+ |
Main stream supports |
| SVC |
Supported in H.264 & H.265 |
| ROI |
1 region for main and sub-stream |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (S/G/T), ISAPI, SDK, Ehome |
| Protocols |
Full range including TCP/IP, RTSP, HTTPS, SNMP, etc. |
| User/Host |
Up to 32 users (Admin/Operator/User) |
| Security |
HTTPS, 802.1X, watermark, IP filtering, ONVIF auth |
| Storage |
MicroSD (up to 128GB), NAS, ANR |
| Clients |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
IE8+, Chrome 57+, Firefox 52+, Safari 11+ |
| Alarm Triggers |
Motion, tampering, network issues, HDD events |
| Day/Night Switch |
Auto/Manual/Schedule |
| DNR |
3D DNR |
| Enhancement |
BLC, HLC |
| Image Settings |
Brightness, contrast, saturation, WB, sharpness |
| Video Output |
No |
| On-board Storage |
Up to 128 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M Ethernet |
| Events |
Basic: motion, tamper, network
Smart: line crossing, intrusion, face detection, etc. |
| Face Detection |
Yes |
| Linkage Method |
Recording, FTP/Email upload, alarm output |
| Firmware |
V5.5.80 |
| Web Languages |
32 languages including English, Arabic, Spanish, etc. |
| General Functions |
Privacy mask, anti-flicker, pixel counter, mirror |
| Operating Conditions |
-30°C to +60°C, ≤ 95% RH |
| Power |
12 VDC ±25%, PoE (802.3af Class 3) |
| Consumption |
12 VDC: 0.5 A (6 W), PoE: Max 7.5 W |
| Dimensions |
70 × 68 × 171 mm |
| Weight |
400 g (camera), 700 g (with package) |
| Protection |
IP67 |
Shipping: Available for immediate shipment
