| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Max. Resolution |
3840 × 2160 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 355°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens Type |
Varifocal motorized lens, 2.8 to 12 mm |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV 108° to 30°, vertical FOV 56° to 17°, diagonal FOV 131° to 35° |
| Lens Mount |
Ø14 |
| Aperture |
Fixed F1.6 |
| DORI |
2.8 to 12 mm: Detect 97 m to 290 m, Observe 38 m to 115 m, Recognize 19 m to 58 m, Identify 9 m to 29 m |
| Supplement Light Type |
Infrared (IR) |
| Supplement Light Range |
Up to 60 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Video Compression |
Main: H.265+/H.265/H.264+/H.264
Sub: H.265/H.264/MJPEG
Third: H.265/H.264 |
| Max. Frame Rate |
30 fps @ 3840 × 2160 (60 Hz), 25 fps (50 Hz) |
| Bit Rate |
32 Kbps to 16 Mbps |
| Wide Dynamic Range (WDR) |
120 dB |
| Region of Interest (ROI) |
1 fixed region for main and sub streams |
| Smart Features |
Human and vehicle classification, line crossing detection, intrusion detection, face detection |
| Network Protocols |
TCP/IP, HTTP, HTTPS, FTP, RTP/RTSP, SNMP, etc. |
| API |
ONVIF (Profile S, Profile G), ISAPI, SDK |
| Users |
Up to 32 users, 3 levels: administrator, operator, user |
| Security |
Password protection, HTTPS encryption, IP filtering, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for ONVIF |
| Storage |
microSD card up to 512 GB, NAS storage, Auto Network Replenishment (ANR) |
| Software |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browsers |
Plugin required for live view: IE 10, IE 11
Plugin-free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Power |
12 VDC ± 25%, 1.08 A, max 13 W, 5.5 mm coaxial power plug with reverse polarity protection
PoE: 802.3at, Class 4, 42.5 to 57 V, 0.36 to 0.27 A, max 15 W |
| Dimensions |
97.9 mm × 93 mm × 308.5 mm |
| Material |
Aluminum alloy body |
| Package Dimensions |
385 mm × 190 mm × 180 mm |
| Weight |
Approx. 1385 g (net) |
| Weight with Package |
Approx. 2046 g |
| Storage Conditions |
-30° to 60° C, humidity ≤ 95% (non-condensing) |
| Operating Conditions |
-30° to 60° C, humidity ≤ 95% (non-condensing) |
| Supported Languages |
33 languages including English, Russian, German, French, Spanish, Traditional Chinese, Japanese, etc. |
| General Functions |
Anti-flicker, password reset via email, pixel counter |
| Approvals |
EMC: FCC, CE-EMC, RCM, KC, IC
Safety: UL, CB, CE-LVD
Environment: CE-RoHS, WEEE, Reach
Protection: IP67 and IK10 |
