| Image Sensor |
1/2.4" Progressive Scan CMOS |
| Max. Resolution |
3200 × 1800 |
| Min. Illumination |
Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
24/7 color imaging |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Lens Type |
Fixed focal lens, 2.8 mm and 4 mm optional |
| Focal Length & FOV |
2.8 mm: Horizontal 117°, Vertical 64°, Diagonal 138°
4 mm: Horizontal 82°, Vertical 45°, Diagonal 95° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.0 |
| Depth of Field |
2.8 mm: 2 m to ∞
4 mm: 3.1 m to ∞ |
| DORI Distances |
2.8 mm: Detect 64 m, Observe 25 m, Recognize 12 m, Identify 6 m
4 mm: Detect 92 m, Observe 36 m, Recognize 18 m, Identify 9 m |
| Supplement Light Type |
White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| Main Stream |
20 fps @ 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720 |
| Sub Stream |
20 fps @ 1280 × 720, 640 × 480, 640 × 360 |
| Video Compression |
H.265+/H.265/H.264+/H.264, MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Profiles |
Baseline, Main, High |
| H.265 Profile |
Main |
| Bit Rate Control |
CBR, VBR |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Audio |
-U model: Mono sound, noise reduction, 8/16 kHz sampling |
| Network Protocols |
TCP/IP, HTTP, RTP, RTSP, FTP, SMTP, etc. |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF, ISAPI, SDK |
| Users |
Up to 32 users with 3 levels (admin, operator, user) |
| Image Settings |
Saturation, brightness, contrast, sharpness, white balance |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| WDR |
120 dB |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Privacy Mask |
4 programmable polygon masks |
| Ethernet Interface |
1 × RJ45 10/100M |
| On-Board Storage |
-F model: microSD up to 512 GB |
| Built-in Microphone |
-U model: Yes |
| Reset Button |
-F model: Yes |
| Event Detection |
Motion detection, video tampering, exceptions |
| Power |
12VDC ±25%, PoE IEEE 802.3af, Max 6.7W |
| Material |
Metal & Plastic |
| Dimensions |
Ø109.9 × 103.6 mm (Ø4.3 × 4.1") |
| Weight |
-L: 380 g, -LUF: 420 g |
| Operating Conditions |
-30°C to 60°C, Humidity ≤ 95% (non-condensing) |
| Languages |
English, Ukrainian |
| Protection |
IP67 |
Shipping: Available for immediate shipment
