| Image Sensor |
1/3" Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 99°, V 55°, D 116°
4 mm: H 76°, V 41°, D 90° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F2.0 |
| DORI |
2.8 mm: D 59 m, O 23 m, R 11 m, I 5 m
4 mm: D 79 m, O 31 m, R 15 m, I 7 m |
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50Hz: 20 fps (2560×1440), 25 fps (1080p, 720p)
60Hz: 20 fps (2560×1440), 24 fps (1080p, 720p) |
| Sub-Stream |
50Hz: 25 fps (720p, 640×480, 640×360)
60Hz: 24 fps (720p, 640×480, 640×360) |
| Video Compression |
Main: H.265+/H.265/H.264+/H.264
Sub: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline/Main/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| ROI |
1 fixed region for main stream |
| Audio |
-U: Mono sound, noise filtering, 8/16 kHz sampling
Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Network Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| API |
ONVIF (Profile S/T/G), ISAPI, SDK |
| User/Host |
Up to 32 users (Admin, Operator, User) |
| Simultaneous Live View |
Up to 6 channels |
| Security |
Password protection, authentication, MAC filter, audit log |
| Client |
iVMS-4200, Hik-Connect |
| Browser |
IE 10/11 (plug-in), Chrome/Firefox (local) |
| WDR |
120 dB |
| SNR |
≥ 52 dB |
| Image Settings |
Rotate, saturation, brightness, contrast, sharpness, gain, white balance |
| Privacy Mask |
4 programmable masks |
| On-Board Storage |
-F: microSD/SDHC/SDXC up to 256 GB |
| Built-in Mic |
-U: Yes |
| Reset Key |
-F: Yes |
| Basic Events |
Motion detection (human/vehicle), tampering, exception |
| Linkage |
FTP/memory card, email, alarm, recording, snapshot |
| Power |
12 VDC ±25%, 0.4 A, max. 5 W; PoE 802.3af Class 3 |
| Material |
Metal & Plastic |
| Dimension |
170.8 × 66 × 69.1 mm |
| Weight |
270 g (device), 481 g (with package) |
| Operating Conditions |
-30 °C to 60 °C, ≤95% RH |
| Languages |
English, Ukrainian |
| Approvals |
EMC, Safety, RoHS, WEEE, Reach |
| Protection |
IP67 |
