| Image Sensor |
1/3" Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens |
Fixed focal lens, 2.8 mm and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H: 98°, V: 54°, D: 114°
4 mm: H: 78°, V: 42°, D: 93° |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| DORI |
2.8 mm: Detect 63 m, Observe 25 m, Recognize 12 m, Identify 6 m
4 mm: Detect 78 m, Observe 31 m, Recognize 15 m, Identify 7 m |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
20 fps (2560×1440)
25 fps (1920×1080, 1280×720) |
| Sub-Stream |
25 fps (1280×720, 640×480, 640×360) |
| Video Compression |
Main: H.265+/H.265/H.264+/H.264
Sub: H.265/H.264/MJPEG |
| Video Bitrate |
32 Kbps to 8 Mbps |
| Audio |
Mono sound, built-in microphone, 8/16 kHz sampling, multiple codecs supported |
| Wide Dynamic Range (WDR) |
120 dB |
| Signal-to-Noise Ratio (SNR) |
≥ 52 dB |
| Privacy Mask |
4 programmable polygonal zones |
| Network Protocols |
TCP/IP, HTTP, RTP, RTSP, etc. |
| Simultaneous Live View |
Up to 6 channels |
| Users |
Up to 32 users (Admin, Operator, User) |
| Security |
Password protection, HTTPS, MAC authentication, audit logs |
| Storage |
Up to 512 GB microSD (for -F model) |
| Power |
12V DC ± 25%, 0.4 A, max 5 W, PoE IEEE 802.3af Class 3 max 6.5 W |
| Material |
Metal & Plastic |
| Dimensions |
170.8 mm × 66 mm × 69.1 mm |
| Weight |
Approx. 270 g |
| Operating Conditions |
-30°C to 60°C, RH ≤ 95% |
| Certifications |
CE-EMC, FCC, UL, RoHS, WEEE, IK08, IP67 |
