| Image Sensor |
1/3" Progressive Scan CMOS |
| Max. Resolution |
2560 × 1440 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 355°, Tilt: 0° to 75°, Rotate: 0° to 355° |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm: H 98°, V 54°, D 114°4 mm: H 78°, V 42°, D 93° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.6 |
| DORI |
2.8 mm: Detect 63 m, Observe 25 m, Recognize 12 m, Identify 6 m4 mm: Detect 78 m, Observe 31 m, Recognize 15 m, Identify 7 m |
| Supplement Light Type |
IR, White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Main Stream |
50 Hz: 20 fps (2560×1440), 25 fps (1920×1080,1280×720)60 Hz: 20 fps (2560×1440), 24 fps (1920×1080,1280×720) |
| Sub-Stream |
50 Hz: 25 fps (1280×720, 640×480, 640×360)60 Hz: 24 fps (1280×720, 640×480, 640×360) |
| Video Compression |
Main: H.265+/H.265/H.264+/H.264Sub: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Audio Type |
Mono sound |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz / 16 kHz |
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711 ulaw/alaw), 16 Kbps (G.722.1/G.726), 32–160 Kbps (MP2L2), 16–64 Kbps (AAC-LC) |
| Security |
Password protection, complicated password, watermark, HTTP authentication, WSSE, MAC authentication, audit logs |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF Profile S, T, G (-F model only), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Users |
Up to 32 (Administrator, Operator, User) |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 10, 11 (plugin required), Chrome 57+, Firefox 52+ |
| WDR |
120 dB |
| SNR |
≥ 52 dB |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Settings |
Rotate, saturation, brightness, contrast, sharpness, gain, white balance; adjustable via client or browser |
| Privacy Mask |
4 programmable polygon masks |
| Ethernet Interface |
1 RJ45 10/100 M self-adaptive port |
| On-board Storage |
-F: microSD/microSDHC/microSDXC slot up to 512 GB |
| Built-in Microphone |
Yes |
| Reset Key |
-F: Yes |
| Basic Event |
Motion detection (supports human & vehicle), video tampering alarm, exception |
| Event Linkage |
Upload to FTP/memory card (-F), send email, notify center, trigger recording (-F), trigger capture |
| Power |
12 VDC ± 25%, 0.5 A, max 6 W, Ø5.5 mm coaxial plug, reverse polarity protection; PoE IEEE 802.3af Class 3 max 7.5 W |
| Material |
Metal & Plastic |
| Dimensions |
Ø121.4 mm × 97.7 mm (Ø4.8" × 3.8") |
| Package Dimensions |
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
| Weight |
Approx. 550 g (1.2 lb.) |
| Package Weight |
Approx. 800 g (1.8 lb.) |
| Storage Conditions |
-30 °C to 60 °C, Humidity ≤ 95% (non-condensing) |
| Operating Conditions |
-30 °C to 60 °C, Humidity ≤ 95% (non-condensing) |
| Languages |
English, Ukrainian |
| General Functions |
Heartbeat, anti-banding, mirror, password protection, password reset via email |
| Certifications |
FCC, CE-EMC, RCM, IC, UL, CB, CE-LVD, BIS |
| Environment |
CE-RoHS, WEEE, Reach |
| Protection |
IP67 (IEC 60529-2013), IK08 (IEC 62262:2002) |
