Cudy 5-Port Gigabit GS105D Unmanaged Switch

Not rated

Out Of Stock Model: GS105D

12 JOD

Add to My Favourite Add to compare

Data sheet

Interface: 5 × Gigabit RJ45 Ports
Switching Capacity: 10 Gbps
Forwarding Rate: 7.44 Mpps

QTY

Add to Cart

Quote Request

Total : 12 JOD

Notify me when available

Description Specifications Customer Reviews

The GS105D is a 5-port Gigabit network switch designed for home and small office networks. With Layer 2 support, a MAC address table of 2048 entries, 10 Gbps switching capacity, and a forwarding rate of 7.44 Mpps, it delivers fast and reliable data transmission. Features include jumbo frame support, low power consumption, and LED indicators for each port. Compact and easy to install on desktops or walls, the GS105D provides an energy-efficient and stable networking solution.

Specifications

Interfaces	5 × Gigabit RJ45 Ports
LED Indicators	Power, Speed/Link/ACT of each Ethernet port
Power Input	DC Jack
Performance	Copper Speed & Distance: - Cat.3 or higher: 100 meters @ 10 Mbps - Cat.5 or higher: 100 meters @ 100 Mbps - Cat.5e or higher: 140 meters @ Gigabit
MAC Address Table	2048 entries
Max Switching Capacity	10 Gbps
Max Forwarding Rate	7.44 Mpps
Jumbo Frame	15 KB
Packet Buffer	3 Mbit
Power Saving	Basic Power Saving: True
Power Methods	DC
DC Rating	5V ⎓ 0.55A
Power Adapter	Input: 100-240V~, 50/60Hz Output: 5V ⎓ 0.55A
Max Power Consumption	2 W
Idle Power Consumption	1.4 W
Switching Protocols	802.3x Flow Control, 802.3i (10BASE-T), 802.3u (100BASE-TX), 802.3ab (1000BASE-T)
EMS/EMC	IEC/EN 61000-4-2, Level 2 ESD: Contact: 4kV; Air: 8kV IEC/EN 61000-4-5, Level 3 Surge: 2kV
Operating Environment	Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉) Humidity: 10% ~ 90% non-condensing
Storage Environment	Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 5% ~ 90% non-condensing
Mechanical Dimensions	88 × 52.5 × 24 mm (3.46 × 2.07 × 0.94 in)
Product Weight	52 g (1.83 oz)
Casing Material	Plastic
Installation	Desktop, Wall-mount
Package Content	GS105D, Power Adapter, Installation Guide
Retail Package Dimension	EU/US: 92×88×57 mm (3.62×3.46×2.24 in)
Retail Package Weight	EU: 137 g (4.83 oz) UK: 170 g (6 oz)
Units per Carton	EU/US: 100
Carton Net Weight	EU: 13.7 kg (30.2 lbs) UK: 17.0 kg (37.48 lbs)
Carton Gross Weight	EU: 16.6 kg (36.6 lbs) UK: 18.2 kg (40.12 lbs)
Carton Dimension	EU/US: 48.7×31.2×38.5 cm (19.17×12.28×15.16 in)
