| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Max. Resolution |
3840 × 2160 |
| Minimum Illumination |
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm: Horizontal FOV 105.1°, Vertical FOV 54.8°, Diagonal FOV 128.2°
4 mm: Horizontal FOV 90.0°, Vertical FOV 45.8°, Diagonal FOV 109.4° |
| Lens Mount |
M16 |
| Iris Type |
Fixed F1.0 |
| Depth of Field |
2.8 mm: 3.3 m to ∞
4 mm: 3.8 m to ∞ |
| DORI Range |
2.8 mm: Detect 89 m, Observe 35 m, Recognize 17 m, Identify 8 m
4 mm: Detect 109 m, Observe 43 m, Recognize 21 m, Identify 10 m |
| Supplemental Light Type |
Infrared and White Light |
| Supplemental Light Range |
Up to 60 meters |
| Smart Light |
Yes |
| IR Wavelength |
850 nm |
| Video |
Main Stream:
50 Hz: 25 fps (3840×2160, 3200×1800, 2688×1520, 1920×1080, 1280×720)
60 Hz: 24 fps (3840×2160), 30 fps (others)
Sub-Stream:
50 Hz: 25 fps (1280×720, 640×480, 640×360)
60 Hz: 30 fps (1280×720, 640×480, 640×360)
Third Stream:
50 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360)
60 Hz: 10 fps (same resolutions above)
*Third stream supported under certain settings. |
| Video Compression |
Main Stream: H.265/H.264/H.264+/H.265+
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264
*Third stream supported under certain settings. |
| Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline, Main, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Scalable Video Coding (SVC) |
Supported for H.264 and H.265 |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profiles S, G, T), ISAPI, SDK, ISUP |
| Users |
Up to 32 users (administrator, operator, user) |
| Security |
Password protection, complex passwords, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest HTTP/HTTPS authentication, WSSE and Digest authentication for ONVIF, RTP/RTSP over HTTPS, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC) |
| Network Storage |
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plugin required live view: IE 10, IE 11
Plugin-free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image Settings |
Rotate, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancements |
BLC, HLC, 3D DNR |
| Signal-to-Noise Ratio (SNR) |
≥ 52 dB |
| Wide Dynamic Range (WDR) |
130 dB |
| Privacy Mask |
4 programmable polygon privacy masks |
| Ethernet Interface |
1 RJ45 10/100 Mbps self-adaptive port |
| On-Board Storage |
Built-in memory card slot, supports microSD/microSDHC/microSDXC up to 512 GB |
| Reset Key |
Yes |
| Basic Events |
Motion detection (supports alarm triggering by specified target types like human and vehicle), video tampering alarm, exceptions |
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email |
| Smart Event |
Scene change detection |
| Deep Learning Functions |
Face capture, perimeter protection (line crossing, intrusion, region entrance, region exit), supports alarm triggering by specific target types (human and vehicle) |
| Power |
12 VDC ± 25%, 0.7 A, max. 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: IEEE 802.3af, Class 3, max. 9.5 W |
| Material |
Front cover: Metal, Body: Metal, Bracket: Metal |
| Dimensions |
286.7 × 93.3 × 91.2 mm (11.3" × 3.7" × 3.6") |
| Package Dimensions |
386 × 156 × 155 mm (15.2" × 6.1" × 6.1") |
| Weight |
Approx. 1085 g (2.4 lb) |
| Weight with Package |
Approx. 1639 g (3.6 lb) |
| Storage Conditions |
-30° to 60° C (-22° to 140° F), Humidity ≤ 95% (non-condensing) |
| Operating Conditions |
-30° to 60° C (-22° to 140° F), Humidity ≤ 95% (non-condensing) |
| General Functions |
Heartbeat, mirror, password reset via email, pixel counter, anti-banding |
| Supported Languages |
33 languages including English, Russian, Arabic, and others |
| Approvals |
EMC: CE-EMC, RCM, IC, KC
Safety: UL, CB, CE-LVD, BIS
Environment: CE-RoHS |
| Protection |
IP67 per IEC 60529-2013 |
