Cudy 5-Port Gigabit GS105 Unmanaged Switch

Not rated

Out Of Stock Model: GS105

15 JOD

Add to My Favourite Add to compare

Data sheet

Interface: 5 × Gigabit RJ45 Ports
Switching Capacity: 10 Gbps
Forwarding Rate: 7.44 Mpps

QTY

Add to Cart

Quote Request

Total : 15 JOD

Notify me when available

Description Specifications Customer Reviews

The GS105 is a high-performance 5-port Gigabit Ethernet switch designed for small networks and home offices. It offers fast data transfer, energy efficiency with basic power-saving features, and reliable Layer 2 connectivity. Perfect for desktop or wall-mount installation, it supports full/half duplex modes and provides a MAC address table of 2048 entries for seamless network management.

Specifications

Interfaces	5 × Gigabit RJ45 Ports
LED Indicators	Power, Speed/Link/ACT of each Ethernet port
Power Input	DC Jack
Performance	Copper Speed & Distance: - Cat.3 or higher cable: 100 meters @ 10 Mbps - Cat.5 or higher cable: 100 meters @ 100 Mbps - Cat.5e or higher cable: 140 meters @ Gigabit
MAC Address Table	2048 entries
Max Switching Capacity	10 Gbps
Max Forwarding Rate	7.44 Mpps
Jumbo Frame	15 KB
Packet Buffer	3 Mbit
Power Saving	Basic Power Saving: True
Power Methods	DC
DC Rating	5V ⎓ 0.55A
Power Adapter	Input: 100-240V~, 50/60Hz Output: 5V ⎓ 0.55A
Max Power Consumption	2 W
Idle Power Consumption	1.4 W
Switching Protocols	802.3x Flow Control, 802.3i (10BASE-T), 802.3u (100BASE-TX), 802.3ab (1000BASE-T)
Reliability / EMS	IEC/EN 61000-4-2, Level 2 ESD: Contact: 4kV; Air: 8kV IEC/EN 61000-4-5, Level 3 Surge: 2kV
Operating Environment	Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉) Humidity: 10% ~ 90% non-condensing
Storage Environment	Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 5% ~ 90% non-condensing
Mechanical Dimensions	86.5 × 53 × 23 mm (3.41 × 2.09 × 0.91 in)
Product Weight	112 g (3.95 oz)
Casing Material	Metal
Installation	Desktop, Wall-mount
Package Content	GS105, Power Adapter, Installation Guide
Retail Package Dimension	EU/US: 92×88×57 mm (3.62×3.46×2.24 in)
Retail Package Weight	EU: 194 g (6.84 oz) UK: 232 g (8.18 oz) US: 201 g (7.09 oz)
Units per Carton	EU/US: 60
Carton Net Weight	EU: 11.6 kg (25.57 lbs) UK: 13.9 kg (30.64 lbs) US: 12.1 kg (26.68 lbs)
Carton Gross Weight	EU: 12.2 kg (26.9 lbs) UK: 14.7 kg (32.41 lbs) US: 12.2 kg (26.9 lbs)
Carton Dimension	EU/US: 38.5×30.5×28.5 cm (15.16×12.01×11.22 in)
